Home ProductsFlat Ring Gasket

High Temp Flat Ring Automotive Gasket Economical Min 250% Elongation

High Temp Flat Ring Automotive Gasket Economical Min 250% Elongation

High Temp Flat Ring Automotive Gasket Economical Min 250% Elongation

Product Details:

Place of Origin: Guangdong,China
Brand Name: ORK
Certification: FDA,ROHS,ISO9001,TS16949
Model Number: Customized

Payment & Shipping Terms:

Minimum Order Quantity: 100 USD
Price: negotiation
Packaging Details: PE inside , Carton Outside
Delivery Time: 7-45 work days
Payment Terms: L/C, L/C,Paypal
Supply Ability: 30000000 PCS / Month
Contact Now
Detailed Product Description
Brand Name: NBR 70 Rubber Flat Ring Gasket Hardness: 70±5 Shore
Brand: ORK Material: NBR
Colour: Black Acild Resistant: Acceptable
Application: Pipe

High Temp Flat Ring Automotive Gasket Economical Min 250% Elongation



Products Features



1 ) We have kinds of material:EPDM,silicone,NBR,neoprene rubber,PVC,TPE,TPV,TPR,PP,ABS.



2 ) High temperature and acid-alkali resistance,anti-gng,no posion and no smell.



3 ) It is an ideal solution for sealing application where there are high temperatures and corrosive liquids or gases involved.



4 ) We offer OEM and we could design,produce according to your drawings or samples.



Quality Control



1. Best Quality raw rubber material.



2 . Advanced equipments and good workmanship.



3 . Customer's design and specifications are accepted.We are ready to customized your products.



4 . Rubber strips are made in various materials and can be made in different sizes and color.





The flowing is NBR 70 TEST REPORT



NBR 70 TEST REPORT

ASTM D2000 M2BG 714 B14 EO14 EF11 EF21 EA14 F17

PROPERITIES

SPECIFICATION

TEST RESULT

TEST METHOD

Hardness shore A

70±5

72

D2240

Tensile MPA Min

14

14.5

D12

Elongation % Min

250

315

D412

Gravity



1.263

D297

Heat resistant 70h 100℃ Hardness change

±15

﹢5

D573

Tensile strength%

±30

﹢15



Elongation Max

-50

-12



Compression Max 22h  at 100℃

25

14

D395

NO1 oil resistant







Change in hardness

-10~+5

+1

D471

Change in tensile Max

-25

-16



Change in Elongation

-45

-20



Change in Volume%

0~25

+6



Fuel resistant 70 H at 23℃







Hardness change

±10

+3

D471

Tensile change Max

-25

-8



Elongation change Max

-25

-10



Change in Volume

-5~+10

+3



Water Resistant





D417

Change in Hardness



+3



Change in tensile



+5



Change in Elongation



-14



Change in Volume

±15

+3



Low Temperature resistant





D2137

3 MIN -40℃

Non brittle

Pass

D2137







High Temp Flat Ring Automotive Gasket Economical Min 250% Elongation
