Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70

Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70

    • Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70
    • Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70
    • Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70
    • Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70
  • Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70

    Product Details:

    Place of Origin: Guangdong,China
    Brand Name: ORK
    Certification: FDA,ROHS,ISO9001,TS16949
    Model Number: Customized

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 USD
    Price: negotiation
    Packaging Details: PE inside , Carton Outside
    Delivery Time: 7-45 work days
    Payment Terms: L/C, Paypal, T/T
    Supply Ability: 30000000 PCS / Month
    Contact Now
    Detailed Product Description
    Brand Name: HNBR 70 O-ring Size: AS568
    Hardness: 70±5 Shore Application: Auto Parts
    Material: Rubber Colour: Colourful



    Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70





    Description:



     O-ring for installation on a variety of machinery and equipment, at a specified temperature, pressure, and various liquid and gaseous media, at rest or in motion from the seal. On the machine, marine, automotive, aerospace equipment, metallurgical machinery, chemical machinery, engineering machinery, construction machinery, mining machinery, petroleum machinery, plastic machinery, agricultural machinery, and a variety of instruments, a large number of applications for various types of seals elements. O-ring is mainly used for static seals and reciprocating seals. For rotational movement of the seal when limited to low-speed rotary sealing device. O-ring is usually installed on the outer or inner circle from the seal section is rectangular trench. O-ring seals still play a good shock absorption in oil, acid, wear, erosion and other environmental chemistry. Therefore, O-ring hydraulic and pneumatic drive system most widely used a seal





    Advantages O-ring:


        O-ring seals in comparison with other types, has the following advantages: - For a variety of seal forms: static seals, dynamic seals Materials for a variety of purposes, size and groove are standardized, interchangeable - For a variety of movement: the rotational motion, or a combination of axial reciprocating motion (such as a combination of rotary reciprocating motion) - Suitable for a variety of different sealing medium: oil, water, gas, chemical, or other media mixed media By appropriate choice of rubber material and appropriate formulation design, implementation, oil, water, air, gas, and various chemical mediators effective seal. Wide temperature range (- 60  ~ + 220 ), fixed using a pressure of up to 1500Kg / cm2 (with reinforcement ring and use). - The design is simple, compact, easy assembly and disassembly O-ring cross-sectional structure is extremely simple, and there is a self-sealing effect, reliable sealing performance. Because O-ring structure itself and the installation site is extremely simple, and has become standardized, so are very easy to install replacement. - Material varieties Can be selected according to different fluids: YES nitrile rubber (NBR), fluoro rubber (FKM), silicone rubber (VMQ), ethylene propylene rubber (EPDM), chloroprene rubber (CR), butyl rubber (BU), poly tetrafluoroethylene (PTFE), natural rubber (NR), etc





    Competitive Advantage:



    1) have all AS568 ,Metric and well used series o ring mould,and parts of other standards

    2) work with buyers worldwide more than 10 years in rubber solution.

    3) high quality with best price

    4) All material can pass FDA test and also have FDA certification

    5) OEM parts mold cost can be return back once your Quantity can reach our requirements.

    6) a very special manufacture in industry for rubber and silicone products





    HNBR 70 TEST REPORT

    ASTM D2000 M2BG 714 B14 EO14 EF11 EF21 EA14 F17

    PROPERITIES

    SPECIFICATION

    TEST RESULT

    TEST METHOD

    Hardness shore A

    70±5

    72

    D2240

    Tensile MPA Min

    14

    14.5

    D12

    Elongation % Min

    250

    315

    D412

    Gravity



    1.263

    D297

    Heat resistant 70h 100℃ Hardness change

    ±15

    ﹢5

    D573

    Tensile strength%

    ±30

    ﹢15



    Elongation Max

    -50

    -12



    Compression Max 22h  at 100℃

    25

    14

    D395

    NO1 oil resistant







    Change in hardness

    -10~+5

    +1

    D471

    Change in tensile Max

    -25

    -16



    Change in Elongation

    -45

    -20



    Change in Volume%

    0~25

    +6



    Fuel resistant 70 H at 23℃







    Hardness change

    ±10

    +3

    D471

    Tensile change Max

    -25

    -8



    Elongation change Max

    -25

    -10



    Change in Volume

    -5~+10

    +3



    Water Resistant





    D417

    Change in Hardness



    +3



    Change in tensile



    +5



    Change in Elongation



    -14



    Change in Volume

    ±15

    +3



    Low Temperature resistant





    D2137

    3 MIN -40℃

    Non brittle

    Pass

    D2137



    O Rings:



    Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70

    Colourful Chemical Auto O Ring Oil Fuel Resistance Professional Hnbr 70
